Fiber Optic Cable OPGW Product Series
Fiber Optic Cable Products
/
OPGW Products
Combines aluminum-clad steel wires (ACS) with stainless steel fiber tubes.
Lightning protection: trapezoidal design enhances current capacity (2000kA²s).
Matches existing ground wire diameter/tension for tower retrofits.
Central tube/layer-strand structures (per DL/T 832-2016) for 2–144 fibers.
High tensile strength (RTS 700kN) and crush resistance (3,000N/100mm).
Operating range: -40°C to +65°C; spans >1,000m.
Eliminates separate comms cables, reducing installation costs by 30%.
