| Rated Voltage |
150V DC |
| Operating Temperature |
-40~120℃ |
| Contact Resistance |
≤0.6mΩ |
| Insulation Resistance |
≥2000MΩ |
| Salt Spray |
48H |
| Wire Connection Method |
Hexagonal Riveting |
|
| Housing Material |
PBT |
| Terminal Material |
Tough Pitch Copper, Silver Plated |
| Board Connector Method |
Soldering |
| Flame Retardant Rating |
UL94 V-0 |
| Glow Wire Flammability Index |
GWFI 850℃ |
| Environmental Performance |
Compliant with RoHS2.0, REACH, PAHS, TSCA, CP65 |
|
| Rated Voltage |
150V DC |
| Operating Temperature |
-40~120℃ |
| Contact Resistance |
≤0.6mΩ |
| Insulation Resistance |
≥2000MΩ |
| Salt Spray |
48H |
| Wire Connection Method |
Hexagonal Riveting |
| Housing Material |
PBT |
| Terminal Material |
Tough Pitch Copper, Silver Plated |
| Board Connector Method |
Soldering |
| Flame Retardant Rating |
UL94 V-0 |
| Glow Wire Flammability Index |
GWFI 850℃ |
| Environmental Performance |
Compliant with RoHS2.0, REACH, PAHS, TSCA, CP65 |
|
